| TÜR |
KODU |
DEPLASMAN cm3 |
Bir mm |
B mm |
C GİRİŞİ |
D ÇIKIŞ |
AĞIRLIK kg |
|---|---|---|---|---|---|---|---|
| FZH 75 | 200FZH075DS | 73 | 127,5 | 194,5 | 1-1/4 | 1 | 18 |
| FZH 85 | 200FZH085DS | 84 | 130 | 198,5 | 1-1/4 | 1 | 18,9 |
| FZH 100 | 200FZH100DS | 100 | 139,5 | 204,5 | 1-1/4 | 1 | 19,8 |
| FZH 116 | 200FZH116DS | 116 | 139,5 | 210,5 | 1-1/4 | 1 | 20,7 |
| FZH 130 | 200FZH130DS | 132 | 135,5 | 216,5 | 1-1/2 | 1 | 21,6 |
| FZH 150 | 200FZH150DS | 148 | 143,5 | 222,5 | 1-1/2 | 1 | 22,5 |
| FZH 62 | 200FZH062DS | 62 | 125,5 | 189,5 | 1 | 3/4 | 17,1 |
| TÜR | KODU |
DEPLASMAN cm3 |
MAKS. SÜREKLİ ÇALIŞMA BASINCI bar |
MAKS ARALIK. ÇALIŞMA BASINCI (MAX 30S) bar |
MAKS. TEPE BASINCI (P <= 0.1S) bar |
MAKS. ARALIK HIZI (P <= 20 BAR) n / dak rpm |
MAKS. SÜREKLİ HIZ (<= P1) n / dak rpm |
MIN ARALIKLI HIZ (<= P2X0.5) (MAX 30S) n / dak rpm |
|---|---|---|---|---|---|---|---|---|
| FZH 75 | 200FZH075DS | 73 | 300 | 320 | 450 | 3800 | 1800 | 300 |
| FZH 85 | 200FZH085DS | 84 | 270 | 310 | 375 | 3500 | 1800 | 300 |
| FZH 100 | 200FZH100DS | 100 | 260 | 290 | 375 | 3500 | 1500 | 250 |
| FZH 116 | 200FZH116DS | 116 | 250 | 280 | 340 | 3000 | 1500 | 250 |
| FZH 130 | 200FZH130DS | 132 | 230 | 270 | 315 | 3000 | 1500 | 250 |
| FZH 150 | 200FZH150DS | 148 | 190 | 230 | 270 | 3000 | 1500 | 250 |
| FZH 62 | 200FZH062DS | 62 | 300 | 350 | 450 | 3800 | 2000 | 400 |
