SPECIFICATIONS AND TECHNICAL DATA
| TYPE | DISPLACEMENT | MAX CONTINUOUS OPERATING PRESSURE | MAX PEAK PRESSURE (P<= 0.1S) | MAX INTERMITTENT SPEED (P<=20 BAR) | MAX CONTINUOUS SPEED (<=P1) | MIN INTERMITTENT SPEED (<=P2X0.5) (MAX 30S) |
| cm3 | bar | bar | n/min r.p.m. | n/min r.p.m. | n/min r.p.m. | |
| FOX 064 SAE B | 201FX064 | 450 | 500 | 2500 | 1900 | 300 |
| TYPE | CODE | INLET PRESSURE (ABSOLUTE) | OPERATING VISCOSITY RANGE | OPTIMAL VISCOSITY RANGE | MAX VISCOSITY AT START-UP | FLUID TEMPERATURE |
| bar | cST | cST | cST | °C | ||
| FOX 064 SAE B | 201FX064 | 0,7 ÷ 1,5 | 9 ÷ 75 | 15 ÷ 46 | 1000 | -0.3125 |
