SPECIFICATIONS AND TECHNICAL DATA
| TYPE |
DISPLAC cm3 |
MAX CONTINUOUS OPERATING PRESSURE bar |
MAX PEAK PRESSURE (P<= 0.1S) bar |
MAX INTERMITTENT SPEED (P<=20 BAR) n/min r.p.m. |
MAX CONTINUOUS SPEED (<=P1) n/min r.p.m. |
MIN INTERMITTENT SPEED (<=P2X0.5) (MAX 30S) n/min r.p.m. |
|---|---|---|---|---|---|---|
| FOX 16 | 201FX016D00 | 450 | 500 | 3000 | 2300 | 300 |
| FOX 25 | 201FX025D00 | 450 | 500 | 3000 | 2300 | 300 |
| TYPE | CODE | INLET PRESSURE (ABSOLUTE) | OPERATING VISCOSITY RANGE | OPTIMAL VISCOSITY RANGE | MAX VISCOSITY AT START-UP | FLUID TEMPERATURE |
| bar | cST | cST | cST | °C | ||
| FOX 16 | 201FX016D00 | 0,7 ÷ 1,5 | 9 ÷ 75 | 15 ÷ 46 | 1000 | -0.3125 |
| 201FX016S00 | ||||||
| FOX 25 | 201FX025D00 | 0,7 ÷ 1,5 | 9 ÷ 75 | 15 ÷ 46 | 1000 | -0.3125 |
| 201FX025S00 |
